NixoSeal GP2 Non-Shrink Engineering Grout
NixoSeal GP2 Non-Shrink Engineering Grout is a high-performance cementitious precision grout specially formulated for structural and heavy-duty engineering applications. It provides excellent flowability, controlled expansion, high early strength, and superior load transfer for machine foundations, base plates, anchor bolts, bridge bearings, precast concrete elements, and industrial equipment installations.
Applications:
Machine Foundations
Base Plate Grouting
Anchor Bolt Fixing
Structural Steel Columns
Bridge Bearings
Precast Concrete Elements
Heavy Industrial Equipment
Wind Turbine Foundations
Power Plants
Manufacturing Facilities
Infrastructure Projects
Industrial Flooring Support
Features & Benefits
High early and ultimate compressive strength
Non-shrink formulation for dimensional stability
Excellent flowability for complete void filling
Superior load transfer between foundation and equipment
High bond strength to concrete and steel
Controlled expansion minimizes shrinkage cracks
Easy mixing and application
Excellent durability under dynamic and static loads
Suitable for interior and exterior applications
Long-lasting structural performance
Standard Compliance
Manufactured in accordance with internationally accepted engineering grout performance requirements and tested under stringent quality control procedures.
Mixing
Use a low-speed mechanical mixer (below 500 RPM).
Add approximately 80–90% of the required water into a clean mixing container.
Gradually add the entire 40 kg bag while continuously mixing.
Mix for at least 3 minutes until a smooth, lump-free consistency is achieved.
Add the remaining water to obtain the desired flowable or pourable consistency.
Do not over-water or re-temper partially set grout.
Water Requirement
| Consistency | Water Required |
|---|---|
| Flowable | 6.0–6.4 Litres per 40 Kg Bag |
| Pourable | 5.6 Litres per 40 Kg Bag |
Packaging
40 Kg HDPE Laminated Bag
Coverage
Approximately 1950 kg/m³ of wet grout
(Approximately 48.7 bags per cubic metre)
Technical Specifications
| Property | Value |
|---|---|
| Product Type | Cementitious Non-Shrink Engineering Grout |
| Colour | Grey |
| Fresh Mortar Density | 2000–2300 kg/m³ |
| Mixing Ratio (Flowable) | 0.15–0.16 Water : Powder |
| Mixing Ratio (Pourable) | 0.14 Water : Powder |
| Pot Life @30°C | Approx. 20 Minutes |
| Initial Setting Time | Approx. 30 Minutes |
| Recommended Pour Thickness | Up to 100 mm |
| Application Temperature | +5°C to +40°C |
| Coverage | Approx. 1950 kg/m³ |
| Packaging | 40 Kg Bag |
Surface Preparation
Concrete surface must be structurally sound, clean, and free from dust, oil, grease, curing compounds, and loose particles.
Pre-soak concrete for 2–6 hours to achieve Saturated Surface Dry (SSD) condition.
Remove all standing water before application.
Steel plates and anchor bolts must be clean and free from rust, oil, paint, or contaminants.
Application Method
Allow mixed grout to stand for approximately 5 minutes before pouring.
Pour continuously from one side to eliminate trapped air.
Complete placement within 15–20 minutes after mixing.
Protect freshly placed grout from rapid drying using wet curing, mist spraying, or curing compounds.
Shelf Life
12 Months
Store in unopened, sealed bags in a cool, dry location away from direct sunlight and moisture.
Precautions
Wear gloves, safety goggles, and a dust mask during mixing and application.
Avoid skin and eye contact.
Wash immediately with clean water if contact occurs.
Do not exceed the recommended water dosage.
Do not use as a general repair mortar or overlay in unconfined areas.
Dispose of waste responsibly according to local regulations.
Ideal For
Industrial Plants
Manufacturing Facilities
Commercial Buildings
Infrastructure Projects
Heavy Engineering
Power Plants
Bridges
Machinery Installation
Steel Fabrication
Construction Contractors
